Unit
No. |
Shaft Dla |
Dimensions(mm) |
Bolt Used |
Weight
(kg) |
|
(in) |
(mm) |
A |
B |
C |
F |
A1 |
S |
G |
H |
J |
E |
I |
Z |
Bi |
N |
(in) |
(mm) |
UCFK 201-8
202-9
202-10
203-11
204-12
UCFK 2Ol
202
203
2O4 |
1/2
9/18
5/8
11/16
3/4 |
12
15
17
20 |
4-11/32
110 |
2-7/15
62 |
2-1/16
52 |
2-1/16
52 |
1
25.5 |
25/64
10 |
1/2
13 |
1-21/32
13 |
1-1/16
27 |
1-17/64
32 |
19/32
15 |
1-5/16
33.3 |
1.2205
31 |
0.5000
12.7 |
5/16 |
|
0.6 |
UCFK 205-14
205-15
205-16
UCFK 205 |
7/8
15/16
1 |
25 |
4-9/16
116 |
2-11/16
68 |
2-1/16
82 |
2-7/32
56 |
1-1/16
27 |
25/04
10 |
1/2
13 |
1/2
13 |
1-1/16
27 |
1-11/32
34 |
5/8
16 |
1-13/32
35.8 |
1.3425
34.1 |
0.5630
14.3 |
5/16 |
M8 |
0.68 |
UCFK 206-18
206-19
206-20
UCFK 206 |
1-1/8
1-3/18
1-1/4 |
30 |
5-1/8
130 |
3-1/18
78 |
2-5/32
55 |
2-9/16
65 |
1-7/32
31 |
25/64
10 |
1/2
13 |
1/2
13 |
1-9/64
29 |
1-37/64
40 |
45/64
18 |
1-37/64
40.2 |
1.5000
38.1 |
0.6260
15.9 |
5/16 |
M8 |
0.9 |
UCFK 207-20
207-21
207-22
207-23
UCFK 207 |
1-1/4
1-5/16
1-3/8
1-7/16 |
35 |
5-21/32
144 |
3-17/32
90 |
2-7/16
62 |
2-3/4
70 |
1-11/32
34 |
25/64
10 |
19/32
15 |
19/32
15 |
1-17/64
32 |
1-13/16
46 |
3/4
19 |
1-3/4
44.4 |
1.6890
42.9 |
0.6890
17.5 |
5/16 |
M8 |
1.3 |
UCFK 208-24
208-25
UCFK 208 |
1-1/2
1-9/16 |
40 |
6-15/32
164 |
3-15/16
100 |
2-27/32
72 |
3-1/16
78 |
1-27/64
36 |
15/32
12 |
5/8
16 |
5/8
16 |
1-39/64
41 |
1-31/32
50 |
53/64
21 |
2-1/64
51.2 |
1.9370
49.2 |
0.7480
19 |
3/8 |
M1O |
1.8 |
UCFK 209-26
209-27
209-28
UCFK 209 |
1-5/8
1-11/16
1-3/4 |
45 |
6-27/32
174 |
4-3/16
106 |
3
76 |
3-5/32
80 |
1-1/2
38 |
15/32
12 |
23/32
18 |
23/32
18 |
1-11/16
43 |
2-1/8
54 |
55/64
22 |
2-1/16
52.2 |
1.9370
49.2 |
0.7480
19 |
3/18 |
M1O |
1.98 |
UCFK 210-30
210-31
UCFK 210 |
1-7/8
1 -15/16 |
50 |
7-1/4
184 |
4-13/32
112 |
3-7/32
82 |
3 3/8
86 |
1-37/64
40 |
15/32
12 |
23/32
18 |
23/32
18 |
1-13/16
46 |
2-9/32
58 |
55/64
22 |
2-5/32
54.6 |
2.0315
51.6 |
0.7480
19 |
3/8 |
M1O |
2.2 |
